| Camera |
| Image Sensor | 1/2.7”2Megapixel progressive CMOS |
| Max. Resolution | 1920 (H) × 1080 (V) |
| ROM | 128 MB |
| RAM | 128 MB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | Manual 1/30 s
0. 215 Lux @F2.0 (Color, 80 IRE); 0.232 Lux @F2.0 (W/B, 80 IRE); 0 Lux (IR on)
Manual 1/3 s
0.0324 Lux @F2.0 (Color, 80 IRE); 0.0334 Lux @F2.0 (W/B, 80 IRE); 0 Lux (IR on) |
| S/N Ratio | >50.6 dB |
| Illumination Distance | 10 m (32.8 ft) (IR LED) |
| Illuminator On/Off Control | Auto |
| Illuminator Number | 1 (IR LED) |
| Pan/Tilt/Rotation Range | Pan: 0°–360°
Tilt: 0°–90° |
| Lens |
| Lens Type | Fixed-focal |
| Mount Type | M12 |
| Focal Length | 2.8 mm |
| Max. Aperture | F2.0 |
| Field of View | Horizontal: 102°
Vertical: 54°
Diagonal: 120° |
| Iris Type | Fixed |
| Close Focus Distance | 0.5 m (1.6 ft) |
| DORI Distance | Detect | Observe | Recognize | Identify |
| 38.6 m (126.6ft) | 15.4 m (50.5 ft) | 7.7 m (25.3 ft) | 3.9 m (12.8 ft) |
| Video |
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG |
| Smart Codec | H.264: Yes
H.265: Yes |
| Video Frame Rate | 50 Hz
Main stream (1920 × 1080 @25 fps), sub stream (640 × 480 @25 fps)
Main stream (1280 × 960 @25 fps), sub stream (640 × 360 @25 fps)
Main stream (1280 × 720 @25 fps), sub stream (320 × 240 @25 fps)
60 Hz
Main stream (1920 × 1080 @30 fps), sub stream (640 × 480 @30 fps)
Main stream (1280 × 960 @30 fps), sub stream (640 × 360 @30 fps)
Main stream (1280 × 720 @30 fps), sub stream (320 × 240 @30 fps) |
| Stream Capability | 2 streams |
| Resolution | 1080p (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); VGA (640 × 480); QVGA (320 × 240) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 184 kbps–6144 kbps
H.265: 73 kbps–6144 kbps |
| Day/Night | Auto (ICR)/Color/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | DWDR |
| White Balance | Auto/natural/street lamp/outdoor/manual/regional custom |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D DNR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Smart Illumination | Yes |
| Image Rotation | 0°/90°/180°/270° |
| Mirror | Yes |
| Privacy Masking | 4 areas |
| Audio |
| Built-in MIC | Yes |
| Audio Compression | AAC; G.711a; G.711Mu |
| Alarm |
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; voltage detection; motion detection; video tampering |
| Network |
| Network | RJ-45 (10/100 Base-T) |
| Wi-Fi | Yes |
| SDK and API | Yes |
| Protocol | HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; IPv4/v6; QoS; NTP |
| Interoperability | ONVIF (Profile T/Profile S/Profile G); CGI; DMSS |
| User/Host | 20 (Total bandwidth: 50 M) |
| Storage | NAS; FTP; SFTP; Micro SD card (256 G) |
| Browser | IE: IE7 and later
Chrome: Chrome 45 and later
Firefox: FireFox 46 and later
Safari: Mac os Safari12 |
| Management Software | DMSS |
| Mobile Phone | IOS; Android |
| Certification |
| Certification | CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
CE-RED: Radio Equipment Directive 2014/53/EU
FCC: 47 CFR FCC Part 15, Subpart B
FCC ID: FCC PART 15C |
| Port |
| Alarm Input | 1 channel in: 5mA 3V–5V DC |
| Alarm Output | 1 channel out: 300mA 12V DC |
| Power |
| Power Supply | 12V DC |
| Power Consumption | Max 2.9W (12V DC) (IR full intensity) |
| Environment |
| Operating Conditions | –10°C to +45°C (14°F to +113°F)/Less than 95%RH |
| Storage Conditions | –40°C to +60°C (–40°F to +140°F) |
| Structure |
| Casing | Plastic |
| Dimensions | Φ78.5 mm × 90.5 mm × 127.8 mm (3.1" × 3.6" × 5.0") (L × W × H) |
| Net Weight | 160 g (0.4 lb) |
| Gross Weight | 360 g (0.8 lb) |
