| Technical Specification | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Wired Zones | ARC2008C-(G): 8 on-board zones ARC2016C-(G): 16 on-board zones | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Alarm Output | 4 relay output (30VDC 1A), expansion to 12(ARM708, ARM716) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Network | 1 10M/100M RJ45 Ethernet port,-G (GSM network) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Log | 5000 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Security service center | 2 groups phone call security center | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Siren | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| PSTN Detect | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| SMS | -G Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Remote Upgrade | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Tamper Alarm | Vandal proof | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Alternate Power | 12V/7AH Lead-acid battery | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Power | DC14.5V, Max 35W | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Working Environment | -10°C-+55°C | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Dimensions | 275*275*77mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Weight | <3kg | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Installation | Wall mounting | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
