Input and Output |
Wireless Protection Zone | Hub: 150-channel wireless peripherals (6 sirens, 64 wireless keyfobs) |
Port |
Buzzer | Hub: Built-in |
Button | Hub: 1 × reset, 1 × power, 1 × AP
Keyfob: 4 (Home, Away, Disarm, and SOS)
Door Detector: 1 × power button
PIR Detector: 1 × power button |
Indicator Light | Hub: 1 for multiple statuses (alarm, arming, disarming, networking, and malfunction)
Keyfob: 1 × two-color status indicator (green: normal, red: abnormal)
Door Detector: 1 × green alarm indicator
PIR Detector: 1 × green alarm indicator |
Storage battery | Hub: Built-in lithium battery |
Network Mode | Single SIM (GSM:900/1800 MHz, WCDMA:B1/B5/B8, LTE-FDD:B1/B3/B5/B7/B8/B20, LTE-TDD:B38/B40/B41); dual SIM single standby |
Network Port | Hub: 1 × RJ-45 10 M/100 M Ethernet port |
Function |
Network Protocol | Hub: TCP/IP, including PPTP, L2TP, DHCP, UPNP, and NTP |
Offline Cache | Hub: Max. 50 entries (ANR) |
Power Failure Protection for Configured Parameters | Hub: Yes |
Remote Update | All: Cloud update |
Video Linkage | Hub: Yes |
SMS | Hub: Yes (up to 5 phone numbers) |
Phone Call | Hub: Yes (up to 5 phone numbers) |
Low Battery Alarm | All: Yes |
Tamper Alarm | Hub: Yes
Door Detector: Yes
PIR Detector: Yes |
User Management | Hub: Share function for App users |
Search | Hub: Searching push messages, device status, and program version. Detecting signal strength.
Keyfob: Signal strength detection
Door Detector: Signal strength detection
PIR Detector: Signal strength detection |
Arm and Disarm | Hub: App; keyfob; schedule |
Wireless |
Carrier Frequency | All: 868.0 MHz–868.6 MHz |
Communication Distance | Hub: Up to 2,000 m (6,561.68 ft) in an open space
Keyfob: Up to 900 m (2,952.76 ft) in an open space
Door Detector: Up to 1,200 m (3,937.01 ft) in an open space
PIR Detector: Up to 1,600 m (5,249.34 ft) in an open space |
Communication Mechanism | All: Two-way |
Encryption Mode | All: AES128 |
Frequency Hopping | All: Yes |
Wi-Fi | Hub: 2.4G |
Peripherals |
External Zone | Door Detector: 1-channel dry contact input |
Temperature |
Measuring Range (Temperature) | Door Detector: –15 °C to +65 °C (+18.8 °F to +149 °F) (indoor)
PIR Detector: –15 °C to +65 °C (+18.8 °F to +149 °F) (indoor) |
Measuring Precision (Temperature) | Door Detector: ± 1 °C (± 33.8 °F)
PIR Detector: ± 1 °C (± 33.8 °F) |
Resolution (Temperature) | Door Detector: 1 °C (33.8 °F)
PIR Detector: 1 °C (33.8 °F) |
Specification |
Sensor | Door Detector: Reed switch
PIR Detector: Dual elements low-noise PIR sensor |
Test Mode | Door Detector: Yes
PIR Detector: Yes |
Scenario | Door Detector: Non-metal doors |
Movement Distance | Door Detector: < 40 mm (1.57") |
Detection Mode | PIR Detector: PIR |
Detection Range | PIR Detector: 12 m (39.37 ft) (90°) with installtion height of 2.2 m (7.21 ft) |
Detection Speed | PIR Detector: 0.3 m/s–3 m/s (0.98 ft/s–9.84 ft/s) |
Pet Immunity Level | PIR Detector: ≤ 18 kg (39.68 lb) |
White Light Resistance Level | PIR Detector: 6500 lx |
Two-way Digital Temperature Compensation | PIR Detector: Yes, no attenuation of detection distance in high temperature |
Sensitivity | PIR Detector: 3 levels adjustable |
General |
Power Supply | Hub: 12 V DC, 1.5 A (Europe, UK and USA power adapters are optional)
Keyfob: CR2032 battery
Door Detector: CR123A battery
PIR Detector: CR123A battery |
Battery Life | Hub: Storage battery standby for 12 Hours
Keyfob: 5 years
Door Detector: 5 years
PIR Detector: 4 years |
Power Consumption | Keyfob: Max. 100 mW
Door Detector: Max. 125 mW
PIR Detector: Max. 120 mW |
Operating environment | Hub: –10 °C to +50 °C (+14 °F to +122 °F) (indoor)
Keyfob: –10 °C to +55 °C (+14 °F to +131 °F) (indoor)
Door Detector: –10 °C to +55 °C (+14 °F to +131 °F) (indoor)
PIR Detector: –10 °C to +55 °C (+14 °F to +131 °F) (indoor)
|
