Technical Specification |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Model |
DHI-HY-GB40A |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Gas Type |
Propane (C3H8) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Alarm Threshold |
10% LEL |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Response Time |
≤30 s |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Supply Voltage |
DC12V |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Power Consumption |
≤0.8W |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Output |
1 valve output, 1 relay output |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Operating Temperature |
–10°C to +55°C (+14°F to +131°F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Relative Humidity |
≤95% RH (non condensing) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Warm-up Period |
180 s |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Alarm Method |
Visual and audible alarm |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Alarm Sound Output |
70dB (A) at 1m (3.28 feet) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Silence |
Support |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Dimensions |
86.6 mm × 86.6 mm × 29.2 mm (3.41" × 3.41" × 1.15") |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Installation |
Wall mount |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Certification |
CE |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
