Working Principle |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Collection Type |
Carbon Monoxide (CO) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Sensor Type |
Electrochemical |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Alarm |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Alarm Type |
CO alarm, fault alarm, low battery warning |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Alarm Volume |
Over 85dB (A) at 3 m (9.84 ft) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Alarm Mode |
Visual and audible alarm |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Silence Function |
Support |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Silence Duration |
About 45 seconds |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Alarm Response Threshold |
50 ppm: 60 min–90 min 100 ppm: 10 min–40 min 300 ppm: < 3 min |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Basic Parameters |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Display |
LCD |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Indicator Light |
LED (red/yellow/green) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
LED Instruction |
Alarm: Red indicator |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Power Supply |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Battery Life |
10 years |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Power Source |
3V CR123A lithium battery (replaceable) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Operating Current |
Monitoring Current: ≤20uA |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Operating Ambient |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Operating Environment |
Indoor use only |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Operating Temperature |
–10°C to +40°C (+14°F to +104°F) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Operating Humidity |
≤95% RH (non condensing) |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Appearance |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Color |
White |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Material |
PC + ABS |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Dimensions |
116.4 mm × 71.7 mm × 28.3 mm (4.58" × 2.82" × 1.11") |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Weight |
125 g |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Installation |
Wall Mount |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Certification |
|||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Certifications |
TÜV and CE listed |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
|
Compliance Standard |
EN 50291-1:2018 |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
