Camera
|
|
Image Sensor
|
1/2.8" CMOS
|
|
Max. Resolution
|
1920 (H) × 1080 (V)
|
|
ROM
|
16 MB
|
|
RAM
|
64 MB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual 1/3 s–1/100000 s
|
|
Min. Illumination
|
0.01 Lux @F2.0
|
|
S/N Ratio
|
>56 dB
|
|
Illumination Distance
|
30 m (98.4 ft)
|
|
Illuminator On/Off Control
|
Auto/Manual
|
|
Illuminator Number
|
18 (IR LED)
|
|
Pan/Tilt/Rotation Range
|
Pan: 0° to 360°
Tilt: 0° to 90°
Rotation: 0° to 360°
|
|
Lens
|
|
Lens Type
|
Fixed-focal
|
|
Lens Mount
|
M12
|
|
Focal Length
|
2.8 mm; 3.6 mm
|
|
Max. Aperture
|
2.8 mm: F2.0
3.6 mm: F2.0
|
|
Field of View
|
2.8 mm: Horizontal: 102°; Vertical: 54°; Diagonal: 120°
3.6 mm: Horizontal: 84°; Vertical: 45°; Diagonal: 100°
|
|
Iris Control
|
Fixed
|
|
Close Focus Distance
|
2.8 mm: 0.5 m (1.6 ft)
3.6 mm: 0.8 m (2.6 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8 mm
|
38.6 m
(126.6 ft)
|
15.4 m
(50.5 ft)
|
7.7 m
( 25.3 ft)
|
3.9 m
(12.8 ft)
|
|
3.6 mm
|
49.7 m
(163.1 ft)
|
19.9 m
(65.3 ft)
|
9.9 m
(32.5 ft)
|
5.0 m
(16.4 ft)
|
|
Video
|
|
Video Compression
|
H.265; H.264; H.264B; MJPEG (only supported by the sub stream)
|
|
Smart Codec
|
Smart H.265+/Smart H.264+
|
|
Video Frame Rate
|
Main Stream:
1920 × 1080 (1 fps–25/30 fps)
Sub stream:
704 × 576 (1 fps–25 fps)
704 × 480 (1 fps–30 fps)
|
|
Stream Capability
|
2 streams
|
|
Resolution
|
1080p (1920 × 1080); 1.3M(1280 × 960);720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6400 kbps
|
|
Day/Night
|
Auto (ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
HLC
|
Yes
|
|
WDR
|
DWDR
|
|
White Balance
|
Auto/natural/street lamp/outdoor/manual/regional custom
|
|
Gain Control
|
Auto/Manual
|
|
Noise Reduction
|
3D NR
|
|
Motion Detection
|
OFF/ON (4 areas, rectangular)
|
|
Region of Interest (RoI)
|
Yes (4 areas)
|
|
Smart Illumination
|
Yes
|
|
Image Rotation
|
0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower)
|
|
Mirror
|
Yes
|
|
Privacy Masking
|
4 areas
|
|
Alarm
|
|
Alarm Event
|
Network disconnection; IP conflict; illegal access; motion detection; video tampering; safety exception
|
|
Network
|
|
Network
|
RJ-45 (10/100 Base-T)
|
|
SDK and API
|
Yes
|
|
Cyber Security
|
Video encryption;configuration encryption; Digest; WSSE; account lockout; security logs; generation and importing of X.509 certification; HTTPS; trusted boot; trusted execution; trusted upgrade
|
|
Network Protocol
|
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; NTP; Multicast
|
|
Interoperability
|
ONVIF (Profile S/Profile T); CGI; P2P; Genetec
|
|
User/Host
|
6 (Total bandwidth: 36 M)
|
|
Storage
|
FTP
|
|
Browser
|
IE
Chrome
Firefox
|
|
Management Software
|
Smart PSS; DSS; DMSS
|
|
Mobile Client
|
IOS; Android
|
|
Certification
|
|
Certifications
|
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
|
|
Power
|
|
Power Supply
|
12V DC/PoE (802.3af)
|
|
Power Consumption
|
Basic power consumption: 1.5W (12V DC); 2.3W (PoE)
Max. power consumption (ICR + H.265+IR intensity): 4.3W (12V DC); 5.5W (PoE)
|
|
Environment
|
|
Operating Conditions
|
-40°C to +60°C (-40°F to +140°F)/less than ≤ 95%
|
|
Storage Temperature
|
-40°C to +60°C (-40°F to +140°F)
|
|
Protection
|
IP67
|
|
Structure
|
|
Casing
|
Metal + plastic
|
|
Product Dimensions
|
164.6 mm × Φ70 mm (6.5" × Φ2.8")
|
|
Net Weight
|
0.39 kg (0.8 lb)
|
|
Gross Weight
|
0.50 kg (1.1 lb)
|
