| Card | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Card Type | Mifare 1 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Card Features | Contactless, high security, all-in-one possible | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Sensor Distance | < 20mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Sensor Time | < 0.5s | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Storage Capacity | 50 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Password | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Keyboard Type | All-touch keypad | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Password Length | 6-12 bits | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Storage Capacity | 50 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Fingerprint | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Sensor | Capacitive | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| False Rejection Rate | ≤0.9% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| False Accept Rate | ≤0.0001% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Fingerprint Capacity | 50 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Battery | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Working Voltage | 6V, “AA”battery (4pcs) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Battery Life | About 1 year (10 units/D) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Low Battery Warning | < DC4.5V | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Emergency Power Supply | 9V battery | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Structure | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Door Thickness | 45-65mm (customizable) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Backset | 60mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Central Distance | 68mm | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Product Standard | GA701-2007 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Material | Zinc alloy | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| General | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Working Temperature | -10°C~+55°C | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Relative Humidity | 10%~93% | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Salt spray test | ≥200h | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Lock case test | ≥100000 times | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Package size | 410*225*155(mm) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Gross weight | 6Kg | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Restore Default | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Reset | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Ring | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Built-in Buzzer | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| Built-in Loudspeaker | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
